| Price | : | To be announced |
| Status | : | Out of Stock |
| Brand | : | Gigabyte |
| Product Code | : | X570 AORUS ELITE |
| General Information | ||
| Model | X570 Aorus Elite |
|
| Brand | Gigabyte | |
| Supported Processor | AMD Socket AM4, support for: AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series/ 3rd Gen Ryzen™/ 2nd Gen Ryzen™/ 2nd Gen Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ with Radeon™ Vega Graphics Processors | |
| Chipset | AMD X570 | |
| Socket | AM4 | |
| Bios | * 1 x 128 Mbit flash * Use of licensed AMI UEFI BIOS * PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
| Form Factor | ATX Form Factor; 30.5cm x 24.4cm | |
| Memory Information | ||
| Memory Types | DDR4 |
|
| Channel | Dual channel memory architecture | |
| Slot | 4 x DDR4 DIMM sockets | |
| Supported Bus Speed | Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200(O.C.) / 2933 / 2667 / 2400 / 2133 MHz memory modules. | |
| Maximum Memory | Supporting up to 128 GB | |
| Graphics Information | ||
| Graphics | * 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version, HDCP 2.3, and HDR. * Maximum shared memory of 16 GB |
|
| Expansion Slots | ||
| PCI | Integrated in the CPU (PCIEX16): - AMD Ryzen™ 5000 Series/ 3rd Gen Ryzen™ Processors: * 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 - AMD Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series/ 2nd Gen Ryzen™ Processors: * 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16 * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. · 2nd Generation AMD Ryzen™ with Radeon™ Vega Graphics processors/AMD Ryzen™ with Radeon™ Vega Graphics processors: * 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x8 Integrated in the Chipset (PCIEX4/PCIEX1): * 1 x PCI Express x16 slot, supporting PCIe 4.0/3.0 and running at x4 (PCIEX4) * 2 x PCI Express x1 slots, supporting PCIe 4.0/3.0 |
|
| Storage Information | ||
| M.2 | 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 4.0/3.0 x4/x2 SSD support) |
|
| SATA | 6 x SATA 6Gb/s connectors | |
| RAID | Support for RAID 0, RAID 1, and RAID 10 | |
| Connector Information | ||
| Internal Connectors | * 1 x 24-pin ATX main power connector * 1 x 8-pin ATX 12V power connector * 1 x CPU fan header * 1 x water cooling CPU fan header * 2 x system fan headers * 2 x addressable LED strip headers * 2 x RGB LED strip headers * 1 x CPU cooler LED strip/RGB LED strip header * 2 x M.2 Socket 3 connectors * 6 x SATA 6Gb/s connectors * 1 x front panel header * 1 x front panel audio header * 1 x USB Type-C™ port, with USB 3.2 Gen 2 support * 2 x USB 3.2 Gen 1 headers * 2 x USB 2.0/1.1 headers * 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) * 1 x Clear CMOS jumper * 1 x Q-Flash Plus button |
|
| Port Information | ||
| USB Port | Integrated in the CPU: * 4 x USB 3.2 Gen 1 ports on the back panel Chipset: * 1 x USB Type-C™ port with USB 3.2 Gen 2 support, available through the internal USB header * 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel * 4 x USB 3.2 Gen 1 ports available through the internal USB headers Chipset+2 USB 2.0 Hubs: * 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers) |
|
| HDMI Port | 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz | |
| LAN Port | Intel® GbE LAN chip (10/100/1000 Mbit) | |
| Audio Port | * Realtek® ALC1200 codec * High Definition Audio * 2/4/5.1/7.1-channel * Support for S/PDIF Out |
|
| Operating Systems | ||
| Supported OS | Support for Windows® 10 64-bit |
|
| Warranty | ||
| Warranty | 03 Years Warranty |
|
The Gigabyte X570S AORUS PRO AX AMD ATX Motherboard supports Support AMD Ryzen 5000, 5000 G, 4000 G, 3000 3000 G, 2000 2000 G-Series Processors. It comes with high-end audio capacitors. These Gigabyte Motherboard high-quality capacitors help deliver high resolution and high fidelity audio to provide the most realistic sound effects for gamers. Buy Gigabyte X570 Aorus Elite AMD AM4 Mainboard at the best price in BD.
For more Motherboard information Please Check Gigabyte Motherboard, MSI Motherboard, Asus Motherboard, Esonic Motherboard, and Asrock Motherboard. And also If you Want to know more different type of IT Product information please Click here.
The Gigabyte X570S AORUS ELITE AX AMD AM4 Motherboard. Its Supported Processor AMD Socket AM4, support for AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series/ 3rd Gen Ryzen™/ 2nd Gen Ryzen™/ 2nd Gen Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ with Radeon™ Vega Graphics Processors. 1 x 128 Mbit flash, Use of licensed AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0. ATX Form Factor; 30.5cm x 24.4cm. Dual-channel memory architecture. Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200(O.C.) / 2933 / 2667 / 2400 / 2133 MHz memory modules. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz. Support for HDMI 2.1 version, HDCP 2.3, and HDR. Maximum shared memory of 16 GB. 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16. 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16. 2nd Generation AMD Ryzen™ with Radeon™ Vega Graphics. 1 x PCI Express x16 slot, supporting PCIe 4.0/3.0 and running at x4 (PCIEX4). 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 4.0/3.0 x4/x2 SSD support). 6 x SATA 6Gb/s connectors. Support for RAID 0, RAID 1, and RAID 10. 1 x 24-pin ATX main power connector. 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only). 1 x USB Type-C™ port with USB 3.2 Gen 2 support, available through the internal USB header. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz. Intel® GbE LAN chip (10/100/1000 Mbit). Realtek® ALC1200 codec.Support for S/PDIF Out. This Gigabyte X570 Aorus Elite AMD AM4 Mainboard. Support for Windows 10 64-bit. You can enjoy 03 Years Warranty. Buy Motherboard from Original Store Ltd and get online delivery at any corner of Bangladesh.
