| Special Price | : | ৳9,700 |
| Regular Price(EMI) | : | ৳10,500 |
| Status | : | In Stock |
| Brand | : | Gigabyte |
| Product Code | : | A520M H |
অর্ডার করার পূর্বে কাস্টমার কেয়ার থেকে পণ্যের স্টক সম্পর্কে জেনে নেয়ার জন্য অনুরোধ করা যাচ্ছে। প্রযুক্তি পণ্যের মূল্য অস্থিতিশীল হওয়ার কারনে যেকোনো মুহূর্তে মূল্য পরিবর্তন হতে পারে।
| General Information | ||
| Model | A520M H | |
| Brand | Gigabyte | |
| Supported Processor | support for: AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 Series Processors |
|
| Chipset | AMD A520 | |
| Socket | AM4 | |
| BIOS | 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
| Form Factor | Micro ATX Form Factor; 24.4cm x 20.5cm | |
| Memory Information | ||
| Memory Types | DDR4 | |
| Channel | Dual Channel | |
| Slot | 2 x DIMM | |
| Supported Bus Speed | Support for DDR4 5100(O.C.) / 4800(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules |
|
| Maximum Memory | up to 64 GB (32 GB single DIMM capacity) | |
| Graphics Information | ||
| Graphics | Integrated Graphics Processor: * 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz * The DVI-D port does not support D-Sub connection by adapter. * 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version, HDCP 2.3, and HDR. |
|
| Expansion Slots | ||
| PCI | CPU: * 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16 Chipset: * 2 x PCI Express x1 slots, supporting PCIe 3.0 |
|
| Storage Information | ||
| M.2 | 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSD support) |
|
| SATA | 4 x SATA 6Gb/s connectors | |
| RAID | Support for RAID 0, RAID 1, and RAID 10 | |
| Connector Information | ||
| Internal Connector | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 1 x addressable LED strip header 1 x RGB LED strip header 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x speaker header 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) 1 x serial port header 1 x chassis intrusion header 1 x Clear CMOS jumper |
|
| Port Information | ||
| PS/2 Port | 1 x PS/2 keyboard/mouse port | |
| USB Port | 4 x USB 3.2 Gen 1 port 2 x USB 2.0/1.1 ports |
|
| HDMI Port | 1 x HDMI port | |
| DVI-D Port | 1 x DVI-D port | |
| Q-Flash Plus Button | 1 x Q-Flash Plus button | |
| LAN Port | 1 x RJ-45 port
Realtek GbE LAN chip (1 Gbit/100 Mbit) |
|
| Audio Jack | 3 x audio jacks | |
| Operating System | ||
| Supported OS | Support for Windows 11 64-bit
Support for Windows 10 64-bit |
|
| Warranty | ||
| Warranty | 03 Years | |
Gigabyte A520M H AM4 Micro ATX Motherboard. The Gigabyte A520M provides customers with advanced features and the latest technologies. GIGABYTE motherboards have upgraded power solutions, the latest storage standards, and outstanding connectivity to optimize gaming performance.
Gigabyte A520M H AM4 Micro ATX Motherboard. The model is A520M H. The brand is Gigabyte. The Motherboard Supports AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 Series Processors. Chipset AMD A520. Socket AM4. Q-Flash Plus: Update BIOS Without Installing the CPU, Memory, and Graphics Card. Anti-Sulfur Resistors Design. Micro ATX Form Factor; 24.4cm x 20.5cm. Dual Channel ECC/ Non-ECC Unbuffered DDR4, 2 DIMMs. 4+3 Phases Pure Digital VRM Solution with Low RDS(on) MOSFETs. Ultra-Fast NVMe PCIe 3.0 x4 M.2 Connector. GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management. RGB FUSION 2.0 Supports Addressable LED & RGB LED Strips. Smart Fan 5 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP. 4 x SATA 6Gb/s connectors. Support for RAID 0, RAID 1, and RAID 10. 1 x PS/2 keyboard/mouse port. 4 x USB 3.2 Gen 1 port & 2 x USB 2.0/1.1 ports. 1 x HDMI port. 1 x DVI-D port. 1 x Q-Flash Plus button. 1 x RJ-45 port. Realtek GbE LAN chip (1 Gbit/100 Mbit). 3 x audio jacks. Supported Operating System Windows 11 64-bit & Windows 10 64-bit. The Gigabyte A520M H AM4 Micro ATX Motherboard comes with 03 years warranty.
