| Price | : | To be announced |
| Status | : | Out of Stock |
| Brand | : | MSI |
| Product Code | : | PRO Z790-A WIFI |
| General Information | ||
| Model | MSI PRO Z790-A WIFI DDR4 | |
| Brand | MSI | |
| Supported Processor | Supports 12th/13th Gen Intel Core Pentium Gold and Celeron Processors | |
| Chipset | INTEL Z790 | |
| Socket | LGA 1700 | |
| Form Factor | ATX 243.84mmx304.8mm | |
| Memory Information | ||
| Memory Types | DDR4 | |
| Channel | Dual-Channel | |
| Slot | 4x DDR4 | |
| Supported Bus Speed | - Memory Support 5333/ 5200/ 5066/ 5000/ 4800/ 4600/ 4533/ 4400/ 4266/ 4000/ 3866/ 3733/ 3600/ 3466/ 3333(O.C.)/ 3200/ 3000/ 2933/ 2800/ 2666/ 2400/ 2133(By JEDCE & POR)
- Max. overclocking frequency:
• 1DPC 1R Max speed up to 5333+ MHz
• 1DPC 2R Max speed up to 4800+ MHz
• 2DPC 1R Max speed up to 4400+ MHz
• 2DPC 2R Max speed up to 4000+ MHz |
|
| Maximum Memory | 128GB | |
| Graphics Information | ||
| Graphics | - 1x HDMI - 1x DisplayPort - Support HDMI™ 2.1 with HDR, maximum resolution of 4K 60Hz* - Support DP 1.4, the maximum resolution of 8K 60Hz* |
|
| Expansion Slots | ||
| PCI | - 3x PCI-E x16 slot - 1x PCI-E x1 slot - PCI_E1 PCIe 5.0 supports up to x16 (From CPU) - PCI_E2 PCIe 3.0 supports up to x1 (From Chipset) - PCI_E3 PCIe 4.0 supports up to x4 (From Chipset) - PCI_E4 PCIe 3.0 supports up to x1 (From Chipset) |
|
| Storage Information | ||
| M.2 | - 4x M.2 slot - M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devices - M.2_2 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices - M.2_3 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices - M.2_4 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices |
|
| SATA | 6x SATA 6G port | |
| RAID | - Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
- Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices |
|
| Connector Information | ||
| Internal Connectors | - 1x Power Connector(ATX_PWR) - 2x Power Connector(CPU_PWR) - 1x CPU Fan - 1x Pump Fan - 6x System Fan - 2x Front Panel (JFP) - 1x Chassis Intrusion (JCI) - 1x Front Audio (JAUD) - 1x TBT connector (JTBT, supports RTD3) - 1x Tuning Controller connector(JDASH) - 3x Addressable V2 RGB LED connector (JARGB_V2) - 1x RGB LED connector(JRGB) - 1x TPM pin header(Support TPM 2.0) - 4x USB 2.0 - 2x USB 3.2 Gen1 Type A - 1x USB 3.2 Gen2 Type C |
|
| Port Information | ||
| HDMI Port | 1x HDMI Port | |
| USB Port | - 2x USB 2.0 (Rear)
- 4x USB 2.0 (Front)
- 2x USB 3.2 Gen1 Type A (Rear)
- 2x USB 3.2 Gen1 Type A (Front)v - 3x USB 3.2 Gen2 Type A (Rear)
- 1x USB 3.2 Gen2 Type C (Front)
- 1x USB 3.2 Gen2x2 Type C (Rear) |
|
| Display Port | 1x Display Port | |
| LAN Port | Intel® 2.5Gbps LAN | |
| Audio Port | - Realtek® ALC4080 Codec
- 7.1-Channel USB High-Performance Audio |
|
| Flashback Button | 1x Flash BIOS Button | |
| Wi-Fi / Bluetooth | 1x Wi-Fi / Bluetooth | |
| S/PDIF-OUT | 1x S/PDIF-OUT | |
| Others Information | ||
| WIRELESS / BLUETOOTH | Intel® Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth® 5.3, FIPS, FISMA |
|
| LED FEATURE | 4x EZ Debug LED | |
| Operating Systems | ||
| Supported OS | Support for Windows 11 64-bit, Windows 10 64-bit |
|
| Warranty | ||
| Warranty | 03 Years Warranty | |
MSI PRO Z790-A WIFI DDR4 12th & 13th Gen ATX Motherboard. The MSI motherboards let you manage speeds and temperatures for all your system and CPU fans in BIOS and software with a simplified graphical interface. You can also set up to 4 temperature targets, which will adjust the fan speeds automatically.
MSI PRO Z790-A WIFI DDR4 12th & 13th Gen ATX Motherboard. The Model is MSI PRO Z790-A WIFI DDR4, Brand MSI, Supported Processor Supports 12th/13th Gen Intel Core Pentium Gold and Celeron Processors, Chipset INTEL Z790, Socket LGA 1700, Form Factor ATX 243.84mmx304.8mm, Memory Types DDR4, Channel Dual-Channel, Slot 4x DDR4, Supported Bus Speed - Memory Support 5333/ 5200/ 5066/ 5000/ 4800/ 4600/ 4533/ 4400/ 4266/ 4000/ 3866/ 3733/ 3600/ 3466/ 3333(O.C.)/ 3200/ 3000/ 2933/ 2800/ 2666/ 2400/ 2133(By JEDCE & POR), - Max. overclocking frequency: • 1DPC 1R Max speed up to 5333+ MHz • 1DPC 2R Max speed up to 4800+ MHz • 2DPC 1R Max speed up to 4400+ MHz • 2DPC 2R Max speed up to 4000+ MHz, Maximum Memory 128GB, Graphics - 3x PCI-E x16 slot, - 1x PCI-E x1 slot, - PCI_E1 PCIe 5.0 supports up to x16 (From CPU), - PCI_E2 PCIe 3.0 supports up to x1 (From Chipset), - PCI_E3 PCIe 4.0 supports up to x4 (From Chipset), - PCI_E4 PCIe 3.0 supports up to x1 (From Chipset), M.2 - 4x M.2 slot, - M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devices, - M.2_2 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices, - M.2_3 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices, - M.2_4 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices, SATA 6x SATA 6G port, RAID - Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices, - Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices. It is Internal Connectors - 1x Power Connector(ATX_PWR), - 2x Power Connector(CPU_PWR), - 1x CPU Fan, - 1x Pump Fan, - 6x System Fan, - 2x Front Panel (JFP), - 1x Chassis Intrusion (JCI), - 1x Front Audio (JAUD), - 1x TBT connector (JTBT, supports RTD3), - 1x Tuning Controller connector(JDASH), - 3x Addressable V2 RGB LED connector (JARGB_V2), - 1x RGB LED connector(JRGB), - 1x TPM pin header(Support TPM 2.0), - 4x USB 2.0, - 2x USB 3.2 Gen1 Type A, - 1x USB 3.2 Gen2 Type C, mWIRELESS / BLUETOOTH Intel® Wi-Fi 6E, The Wireless module is pre-installed in the M.2 (Key-E) slot, Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps, Supports 802.11 a/ b/ g/ n/ ac/ ax, Supports Bluetooth® 5.3, FIPS, FISMA, Supported OS Support for Windows 11 64-bit, Windows 10 64-bit. It is MSI PRO Z790-A WIFI DDR4 12th & 13th Gen ATX Motherboard has a 03 Years Warranty.
