| Price | : | To be announced |
| Status | : | Out of Stock |
| Brand | : | Asus |
| Product Code | : | Z490 |
| General Information | ||
| Model | Asus TUF Z490-Plus | |
| Brand | Asus | |
| Supported Processor | Build-in Intel® Socket 1200 for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors | |
| Chipset | Build in Intel® Z490 | |
| Socket | Intel® Socket 1200 | |
| BIOS | 192 (128+64) Mb Flash ROM, UEFI AMI BIOS | |
| Form Factor | ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) | |
| Memory Information | ||
| Memory Types | DDR4 | |
| Channel | Dual Channel | |
| Slot | 4 x DDR4 DIMM | |
| Supported Bus Speed | 4600/ 4500/ 4400/ 4266 / 4133/ 4000/ 3866/ 3733/ 3600/ 3466/ 3400/ 3333/ 3200/ 3000/ 2933/ 2800(O.C.)/ 2666/ 2400/ 2133 MHz Non-ECC, Un-buffered Memory | |
| Maximum Memory | 128 GB | |
| Graphics Information | ||
| Graphics | * 1 x DisplayPort 1.4 ** * 1 x HDMI 1.4b * Graphics specifications may vary between CPU types. * Support DisplayPort 1.4 with max. resolution of 4096 x 2304 |
|
| Expansion Slots | ||
| PCI | * 1 x PCIe 3.0 x16 (x16 mode) * 1 x PCIe 3.0 x16 (x4 mode) * 3 x PCIe x1 |
|
| Storage Information | ||
| M.2 | * 1 x M.2_1 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)*1 * 1 x M.2_2 socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)*2 |
|
| SATA | 6 x SATA 6Gb/s port(s) | |
| RAID | Support Raid 0, 1, 5, 10 | |
| Connector Information | ||
| Internal Connectors | * 1 x CPU Fan connector(s) * 1 x CPU OPT Fan connector(s) * 3 x Chassis Fan connector(s) * 1 x AIO_PUMP connector * 2 x Aura RGB Strip Headers * 1 x Addressable Gen 2 header(s) * 1 x USB 3.2 Gen2 connector support additional 1 USB ports(20-pin, Type-C) * 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) * 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) * 2 x M.2 Socket 3 * 6 x SATA 6Gb/s connector(s) * 1 x Thunderbolt header(s) * 1 x 24-pin EATX Power connector(s) * 1 x 8-pin ATX 12V Power connector(s) * 1 x 4-pin ATX 12V Power connector(s) * 1 x Front panel audio connector(s) (AAFP) * 1 x System panel(s) (Chassis intrusion header is inbuilt) * 1 x Clear CMOS jumper(s) * 1 x COM port header |
|
| Port Information | ||
| PS/2 Port | 1 x PS/2 keyboard/mouse combo port(s) | |
| USB Port | * 2 x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C®) * 4 x USB 3.2 Gen 1 (blue) Type-A |
|
| HDMI Port | 1 x HDMI | |
| DisplayPort | 1 x DisplayPort | |
| LAN Port | * 1 x LAN (RJ45) port(s) * Intel® I219-V 1Gb Ethernet * TUF LANGuard |
|
| Audio Port | 5 x Audio jack(s) | |
| Optical S/PDIF | 1 x Optical S/PDIF out | |
| Other Information | ||
| Special Features | ASUS Exclusive Software Armoury Crate - Aura Sync AI Suite 3: - Performance And Power Saving Utility Turbo V Evo EPU Digi+ VRM Fan Xpert 4 System information - EZ update AI Charger ASUS Turbo LAN DTS Custom for GAMING Headsets Norton Anti-virus software (Free Trial for 90 days) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode ASUS TUF PROTECTION - ASUS DIGI+ VRM (- Digital power design with Dr. MOS) - ASUS Enhanced DRAM Overcurrent Protection - ASUS ESD Guards - TUF LANGuard - ASUS Overvoltage Protection - ASUS SafeSlot - ASUS Stainless-Steel Back I/O ASUS Q-Design - ASUS Q-DIMM - ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - ASUS Q-Slot ASUS Thermal Solution - Stylish heatsink ASUS EZ DIY - Procool AURA Sync - Standard RGB headers - Addressable Gen 2 RGB header |
|
| Operating System | ||
| Supported OS | Windows® 10 64-bit | |
| Warranty | ||
| Warranty | 03 Years | |
Asus TUF Z490-Plus motherboard gives you the strong foundation you expect in your first form, in addition to the versatility of developing with your aspirations. We've put together all the cool stuff with basic planning and design in the latest Build-in Intel® Socket 1200 for 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors support, so you can benefit from industry-driven advances, including tuning of mechanical structures. Extensive cooling control, and lively locally available sound.
For more Motherboard information Please Check Gigabyte Motherboard, MSI Motherboard, Asus Motherboard, Esonic Motherboard, and Asrock Motherboard. And also If you Want to know more different type of IT Product information please Click here.
Asus TUF Z490-Plus Motherboard comes with 10th Gen Intel Core, Pentium Gold and Celeron Processors, Intel Socket 1200, Build in Intel Z490 Chipset with 192 (128+64) Mb Flash ROM, UEFI AMI BIOS, 30.5 cm x 24.4 cm ATX Form Factor. Asus TUF Z490-Plus Motherboard Maximum 128 GB DDR4 Dual Channel Memory, 4 x DDR4 DIMM attachments, Supported Bus Speed 4600/ 4500/ 4400/ 4266/ 4133/ 4000/ 3866/ 3733/ 3600/ 3466/ 3400/ 3333/ 3200/ 3000/ 2933/ 2800(O.C.)/ 2666/ 2400/ 2133 MHz Non-ECC, It is Un-cushioned Memory.TUF Z490-Plus Asus Motherboard comes with standard Graphics such as 1 x Display Port 1.4, 1 x HDMI 2.1, Support DisplayPort 1.4 with max. Resolution of 4096 x 2304 Hz. The Asus TUF Z490-Plus Gaming Motherboard Expansion PCI Slots is 1 x PCIe 3.0/4.0 x 16 slots, 6 x SATA 6 GB/s, 1 x M.2_2 socket 3, Supported Raid 0, 1, 5, 10 also various Internal Connectors such as 1 x 24-pin ATX main power connector, 1 x 4 pin CPU fan header, 1 x M.2_FAN connector, etc. TUF Z490-Plus Asus Motherboard has 1 x LAN (RJ45) port(s), Intel® I219-V 1Gb Ethernet Lan port, 4 USB 3.2 Gen 1, 2 USB 2.0 ports, 5 x Audio jack(s). This Asus TUF Z490-Plus Motherboard has some special features like ASUS Exclusive Software.
Asus TUF Z490-Plus Motherboard Support for Windows 10 64-bit. You can enjoy a 03 Years Warranty. Purchase Motherboard from Original Store Ltd and get online conveyance at any side of Bangladesh.
