| Price | : | To be announced |
| Status | : | Out of Stock |
| Brand | : | Asus |
| Product Code | : | ROG MAXIMUS XII HERO Z490 |
| General Information | ||
| Model | ASUS ROG MAXIMUS XII HERO |
|
| Brand | Asus | |
| Supported Processor | Intel Socket 1200 for 10th Gen Intel Core, Pentium Gold and Celeron Processors Supports Intel 14 nm CPU Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 |
|
| Chipset | Intel® Z490 | |
| Socket | Intel® Socket 1200 | |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS | |
| Form Factor | ATX Form Factor 12 inch x 9.5 inch ( 30.5 cm x 24.4 cm ) | |
| Memory Information | ||
| Memory Types | DDR4 |
|
| Channel | Dual Channel | |
| Slot | 4 x DDR4 DIMM | |
| Supported Bus Speed | 4800(O.C.)/ 4700(O.C)/ 4600(O.C)/ 4500(O.C)/ 4400(O.C)/ 4266(O.C.)/ 4133(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3733(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3333(O.C.)/ 3200(O.C.)/ 3000(O.C.)/ 2933/ 2800/ 2666/ 2400/ 2133 MHz Non-ECC, Un-buffered MemorySupports Intel Extreme Memory Profile (XMP)OptiMem III | |
| Maximum Memory | 128 GB | |
| Graphics Information | ||
| Graphics | * Integrated Graphics Processor * 1 x HDMI 1.4b * Supports NVIDIA 2-Way SLI Technology * Supports AMD 3-Way CrossFireX™ Technology * Supports AMD 2-Way CrossFireX Technology |
|
| Expansion Slots | ||
| PCI | Intel 10th Gen Processors * 2 x PCIe 3.0 x16 (x16 or dual x8) Intel Z490 Chipset * 1 x PCIe 3.0 x16 (x4 mode) * 3 x PCIe 3.0 x1 |
|
| Storage Information | ||
| M.2 | * 1 x M.2_1 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode) * 1 x M.2_2 socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode) * 1 x M.2_3 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode) |
|
| SATA | 6 x SATA 6Gb/s port(s) | |
| RAID | Support Raid 0, 1, 5, 10 | |
| Connector Information | ||
| Internal Connectors | * 1 x CPU Fan connector(s) * 1 x CPU OPT Fan connector(s) * 3 x Chassis Fan connector(s) * 1 x AIO_PUMP connector * 1 x H_AMP fan connector * 1 x W_PUMP+ connector * 1 x W_IN header * 1 x W_OUT header * 1 x W_FLOW header * 1 x AAFP connector * 2 x Aura RGB Strip Headers * 2 x Addressable Gen 2 header(s) * 1 x USB 3.2 Gen 1 front panel TypeC connector * 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) * 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) * 3 x M.2 Socket 3 * 6 x SATA 6Gb/s connector(s) * 1 x Thunderbolt header(s) * 1 x 24-pin EATX Power connector(s) * 1 x 8-pin ATX 12V Power connector(s) * 1 x 4-pin ATX 12V Power connector(s) * 1 x Thermal sensor connector(s) * 1 x ReTry button * 1 x System panel connector * 1 x Speaker connector * 1 x Start button * 1 x FlexKey button |
|
| Port Information | ||
| USB Port | * 4 x USB 3.2 Gen 2 port(s)(3 + Type-A +1 + USB Type-C®) * 4 x USB 3.2 Gen 1 port(s)(4 x Type-A) Front USB Port ( Total 7 ) Rear USB Port ( Total 10 ) * 2 x USB 2.0 port(s)(2 x Type-A) * 2 x USB 3.2 Gen 1 port(s) * 1 x USB 3.2 Gen 2 front panel connector port(s) * 4 x USB 2.0 port(s) |
|
| HDMI Port | 1 x HDMI port | |
| LAN Port | * Intel® I219-V 1Gb Ethernet * Marvell® AQtion AQC111C 5Gb Ethernet * ASUS LANGuard |
|
| Audio Port | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC S1220 - Impedance sense for front and rear headphone outputs - Supports : Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input - ESS™ ES9023 DAC + RC4580 OP AMP - Supports up to 32-Bit/192kHz playback Audio Feature : - SupremeFX Shielding Technology - Gold-plated jacks - Optical S/PDIF out port(s) at back panel - Premium Japanese audio capacitors - Audio Cover | |
| Other Information | ||
| Special Features | Wireless Data Network Intel® Wi-Fi 6 AX201 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) support 1024QAM/OFDMA/MU-MIMO Supports up to 2.4Gbps max data rate Supports CNVI interface Supports dual band frequency 2.4/5 GHz Supports channel bandwidth: HT20/HT40/HT80/HT160 Bluetooth Bluetooth v5.1* *BT 5.1 function will be ready in Windows 10 build 19041 or later. [ROG Exclusive Software] * Mem Tweakit * RAMCache III * ROG CPU-Z * GameFirst VI * Sonic Studio III + Sonic Studio Virtual Mixer * Sonic Radar III * DTS® Sound Unbound * Overwolf * BullGuard Internet Security (1-year full version) [ASUS Exclusive Software] Armoury Crate * Aura Creator * Aura Sync AI Suite 3 * 5-way Optimization with AI Overclocking: TPU, EPU, Digi+ Power Control, Fan Xpert 4, Turbo app * EZ update AI Charger WinRAR [UEFI BIOS] AI Overclocking Guide ASUS EZ DIY * ASUS CrashFree BIOS 3 * ASUS EZ Flash 3 * ASUS UEFI BIOS EZ Mode FlexKey ASUS Special Features ROG Extreme OC kit * FlexKey button * ReTry button * Start button Extreme Engine Digi+ * 10K Black Metallic Capacitors * MicroFine Alloy Choke ASUS Q-Design * ASUS Q-Code * ASUS Q-Connector * ASUS Q-DIMM * ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) * ASUS Q-Slot ASUS Thermal Solution * Aluminum M.2 heatsink cover ASUS EZ DIY * BIOS Flashback™ button * Clear CMOS button * Procool II * Pre-mounted I/O shield * SafeSlot AURA Sync * Standard RGB headers * Addressable Gen 2 RGB headers |
|
| Operating System | ||
| Supported OS | Windows® 10 64-bit |
|
| Warranty | ||
| Warranty | 03 Year Warranty |
|
ASUS ROG MAXIMUS XII HERO WI-FI Z490 motherboard gives you the strong foundation you expect in your first form, in addition to the versatility of developing with your aspirations. We've put together all the cool stuff with basic planning and design in the latest Build-in Intel Socket 1200 for 10th Gen Intel Core, Pentium Gold and Celeron Processors support, so you can benefit from industry-driven advances, including tuning of mechanical structures. Extensive cooling control, and lively locally available sound.
For more Motherboard information Please Check Gigabyte Motherboard, MSI Motherboard, Asus Motherboard, Esonic Motherboard, and Asrock Motherboard. And also If you Want to know more different type of IT Product information please Click here.
ASUS ROG MAXIMUS XII HERO Motherboard comes with 10th Gen Intel Core, Pentium Gold and Celeron Processors Support Intel 14 nm CPU Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0, Intel Socket LGA1200, Build in Intel Z490 Chipset with 256 Mb Flash ROM, UEFI AMI BIOS, 30.5 cm x 24.4 cm ATX Form Factor. ASUS ROG MAXIMUS XII HERO Motherboard Maximum 128 GB DDR4 Dual Channel Memory, 4 x DDR4 DIMM sockets, Supported Bus Speed 4800(O.C.)/ 4700(O.C)/ 4600(O.C)/ 4500(O.C)/ 4400(O.C)/ 4266(O.C.)/ 4133(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3733(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3333(O.C.)/ 3200(O.C.)/ 3000(O.C.)/ 2933/ 2800/ 2666/ 2400/ 2133 MHz Non-ECC, It is Un-buffered MemorySupports Intel Extreme Memory Profile (XMP)OptiMem III. ROG MAXIMUS XII HERO ASUS Motherboard comes with standard Graphics such as 1 x Display Port 1.4, 2 x HDMI 2.0, and Supports NVIDIA 2-Way SLI® Technology. The ASUS ROG MAXIMUS XII HERO WiFi Motherboard Expansion PCI Slots is 1 x PCIe 3.0/4.0 x 16 slots, 6 x SATA 6 GB/s, 1 x M.2_2 socket 3, Supported Raid 0, 1, 5, 10 also various Internal Connectors such as 1 x 24-pin ATX main power connector, 1 x 4 pin CPU fan header, 1 x M.2_FAN connector, etc. ASUS ROG MAXIMUS XII HERO Intel Motherboard has Intel® I219-V 1Gb Ethernet, Marvell® AQtion AQC111C 5Gb Ethernet, ASUS LANGuard, ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC S1220 - Impedance sense for front and rear headphone outputs - Supports Multi-streaming, ASUS ROG MAXIMUS XII HERO Motherboard has some special features like Wireless Data Network Intel® Wi-Fi 6 AX201 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) support 024QAM/OFDMA/MU-MIMO, ASUS Exclusive Software.
ASUS ROG MAXIMUS XII HERO Motherboard Support for Windows 10 64-bit. You can enjoy 03 Years Warranty. Purchase Motherboard from Original Store Ltd and get online conveyance at any side of Bangladesh.
