| Price | : | To be announced |
| Status | : | Out of Stock |
| Brand | : | Asus |
| Product Code | : | ROG MAXIMUS X APEX |
| General Information | ||
| Model | Asus ROG Maximus X APEX | |
| Supported Processor | Intel® Socket 11519th / 8th Gen Intel® Core™, Pentium® Gold and Celeron® Processors | |
| Chipset | Intel® Z370 | |
| Socket | 1151 | |
| BIOS | 2 x 128 Mbit Flash ROM | |
| Form Factor | ATX Form Factor 12 inch x 10.7 inch | |
| Memory Information | ||
| Memory Types | DDR4 | |
| Channel | Dual-Channel | |
| Slot | 2 x DIMM | |
| Supported Bus Speed | 4500(O.C)/ 4333/ 4266/ 4200/ 4133/ 4000/ 3866/ 3733/ 3466/ 3400/ 3333/ 3200/ 3000/ 2800/ 2666/ 2400/ 2133 MHz | |
| Maximum Memory | 32GB | |
| Graphics Information | ||
| Graphics | * Integrated Graphics Processor- Intel® HD Graphics support * Multi-VGA output support : HDMI/DisplayPort ports * Supports HDMI with max. resolution 4096 x 2160 @ 24Hz * Supports DisplayPort 1.2 with max. resolution 4096 x 2304 @ 60 Hz * Maximum shared memory of 1024 MB (for iGPU exclusively) |
|
| Expansion Slots | ||
| PCI | * 3 x PCIe 3.0 x16 (x16 or dual x8 or x8/x4/x4) * 1 x PCIe 3.0 x16 (max at x4 mode) * 2 x PCIe 3.0/2.0 x1 |
|
| Storage Information | ||
| M.2 | 1 x ROG DIMM.2 Module support | |
| SATA | 4 x SATA 6Gb/s port(s) | |
| RAID | Support Raid 0, 1, 5, 10 | |
| Connector Information | ||
| Internal Connectors | * 4 x Aura RGB Strip Headers * 1 x 3D Mount screw port(s) * 1 x ROG extension (ROG_EXT) header(s) * 1 x Q_Code * 9 x ProbeIt Measurement Points * 3 x 4-pin Full Speed Fan connectors * 3 x onboard LED ON/OFF jumper(s) * * 1 x MemOK! button(s) * 3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s) * 1 x 4-pin EZ_PLUG Power connector(s) * 2 x Thermal sensor connector(s) * 1 x BIOS Switch button(s) * 1 x PCIe x 16 lane switch * 1 x DIMM.2 Slot supports 2 M.2 drives (2242-22* 1* 10) * 1 x PAUSE Switch * 1 x RSVD Switch * 1 x AAFP connector * 1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) * 1 x CPU Fan connector(s) * 1 x CPU OPT Fan connector(s) * 3 x Chassis Fan connector(s) * 1 x AIO_PUMP connector * 1 x W_PUMP+ connector * 1 x 24-pin EATX Power connector(s) * 2 x 8-pin ATX 12V Power connector(s) * 1 x Slow Mode switch(es) * 1 x Power-on button(s) * 1 x Reset button(s) * 1 x LN2 Mode jumper(s) * 1 x Safe Boot button * 1 x ReTry button * 1 x 14- 1 pin TPM connector * 1 x W_IN header * 1 x W_OUT header * 1 x W_FLOW header |
|
| Port Information | ||
| PS/2 Port | * 1 x PS/2 keyboard (purple) * 1 x PS/2 mouse (green) |
|
| USB Port | * 1 x USB 3.1 Gen 2 (red)Type-A * 1 x USB 3.1 (black)USB Type-CTM * 6 x USB 3.1 Gen 1 (blue) |
|
| HDMI Port | 1 x HDMI | |
| LAN Port | * Intel® I219V, Dual interconnect between the Integrated Media Access Controller (MAC) * 1 x LAN (RJ45) port(s) |
|
| Audio Port | 5 x Gold-plated audio jacks | |
| Operating System | ||
| Supported OS | Windows® 10 64-bit | |
| Warranty | ||
| Warranty | 03 Years Warranty | |
Asus ROG Maximus X APEX Z370 motherboard gives you the strong foundation you expect in your first form and the versatility of developing with your aspirations. We've put together all the cool stuff with essential planning and design in the latest 8th/9th Gen Intel Core, Pentium Gold, and Celeron Processors support so that you can benefit from industry-driven advances, including tuning of mechanical structures. Extensive cooling control, and lively locally available sound.
For more Motherboard information Please Check Gigabyte Motherboard, MSI Motherboard, Asus Motherboard, Esonic Motherboard, and Asrock Motherboard. And also If you Want to know more different type of IT Product information please Click here.
Asus ROG Maximus X APEX Z370 motherboard comes with Intel Socket 1151 8th/9th Gen Intel® Core, Pentium Gold, and Celeron Processors, Chipset Intel Z370, BIOS 2 x 128 Mbit Flash ROM, ATX Form Factor (12 inch x 10.7 inch), Dual Channel 2 x DIMM DDR4 Maximum Memory 32GB, Supported Bus Speed DDR4 4500(O.C)/ 4333/ 4266/ 4200/ 4133/ 4000/ 3866/ 3733/ 3400/ 3333/ 3200/ 3000/ 2666/ 2400/ 2133 MHz. In this Asus ROG Maximus X APEX Z370 motherboard, Multi-VGA output support: HDMI/DisplayPort ports, Supports HDMI with max. resolution 4096 x 2160 @ 24Hz, Also, DisplayPort 1.2 with max. resolution 4096 x 2304 @ 60 Hz, and the maximum shared memory of 1024 MB. Also in this Asus ROG Maximus X APEX Z370 motherboard, Expansion Slots are 3 x PCIe 3.0 x16 (x16 or dual x8 or x8/x4/x4), 1 x PCIe 3.0 x16 (max at x4 mode), 2 x PCIe 3.0/2.0 x1. Moreover, Storage ports are 1 x ROG DIMM.2 Module support, 4 x SATA 6Gb/s port(s), Support Raid 0, 1, 5, 10. Also in this motherboard, Internal Connectors are 4 x Aura RGB Strip Headers, 3 x 4-pin Full Speed Fan connectors, 1 x 4-pin EZ_PLUG Power connector(s), 1 x BIOS Switch button(s), 1 x PAUSE Switch, 1 x RSVD Switch, 1 x CPU Fan connector(s), 1 x CPU OPT Fan connector(s), 3 x Chassis Fan connector(s), 1 x 24-pin EATX Power connector(s), 2 x 8-pin ATX 12V Power connector(s), 1 x Slow Mode switch(es), 1 x LN2 Mode jumper(s), 1 x Safe Boot button, Moreover, Others ports are 1 x PS/2 mouse (green), 1 x PS/2 keyboard (purple), an the USB ports are 1 x USB 3.1 Gen 2 (red)Type-A, 1 x USB 3.1 (black)USB Type-CTM, 6 x USB 3.1 Gen 1 (blue), Intel I219V, Dual interconnect between the Integrated Media Access Controller (MAC), 1 x LAN (RJ45) port(s), 5 x Gold-plated audio jacks.
Asus ROG Maximus X APEX Z370 motherboard OS Support Windows® 10 64-bit. You can enjoy a 03 Years Warranty. Purchase Motherboard from Original Store Ltd and get online conveyance on any side of Bangladesh.
