| Price | : | To be announced |
| Status | : | Out of Stock |
| Brand | : | Asus |
| Product Code | : | Prime B365M-A |
| General Information | ||
| Model | Asus Prime B365M-A |
|
| Brand | Asus | |
| Supported Processor | 8th/9th Generation Intel Celeron/Pentium®/Core i3/i5/i7 Processors | |
| Chipset | Intel® B365 | |
| Socket | LGA1151 | |
| Bios | 128Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F3 My Favorites, Last Modified log, F6 Qfan Control, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information | |
| Form Factor | mATX Form Factor, 9.6 inch x 8.6 inch ( 24.4 cm x 21.8 cm ) | |
| Memory Information | ||
| Memory Types | DDR4 |
|
| Channel | Dual Channel | |
| Slot | 4 x DIMM | |
| Supported Bus Speed | 2666/2400/2133 MHz | |
| Maximum Memory | 64GB | |
| Graphics Information | ||
| Graphics | * Integrated Graphics Processor- Intel® HD Graphics support * Multi-VGA output support : HDMI/DVI-D/D-Sub ports - Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 30 Hz - Supports DVI with max. resolution 1920 x 1200 @ 60 Hz - Supports D-sub with max. resolution 1920 x 1200 @ 60 Hz * Maximum shared memory of 1024 MB (for iGPU exclusively) * Supports Intel® InTru™ 3D, Quick Sync Video, Clear Video HD Technology, Insider™ |
|
| Expansion Slots | ||
| PCI | * 1 x PCIe 3.0 x16 (x16 mode) * 2 x PCIe 3.0/2.0 x1 |
|
| Storage Information | ||
| M.2 | * 1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode) * 1 x M.2 Socket 3, , with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode) |
|
| SATA | 6 x SATA 6Gb/s port(s), gray | |
| RAID | Support Raid 0, 1, 5, 10 | |
| Connector Information | ||
| Internal Connectors | * 1 x Aura RGB Strip Header * 1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin) * 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) * 2 x M.2 Socket 3 for M Key, type 2242/2260/2280 devices * 1 x TPM header * 1 x LPT header * 1 x COM port(s) connector(s) * 6 x SATA 6Gb/s connector(s) * 1 x CPU Fan connector(s) * 2 x Chassis Fan connector(s) * 1 x S/PDIF out header(s) * 1 x 24-pin EATX Power connector(s) * 1 x 8-pin EATX 12V Power connectors * 1 x Front panel audio connector(s) (AAFP) * 1 x Clear CMOS jumper(s) * 1 x System panel connector * 1 x Chassis intrusion header * 1 x Speaker connector |
|
| Port Information | ||
| PS/2 Port | * 1 x PS/2 keyboard (purple) * 1 x PS/2 mouse (green) |
|
| USB Port | * 7 x USB 3.1 Gen 1 up to 5Gbps port(s) (5 at back panel, , 4 x Type-A+1 x Type-C, 2 at mid-board) * 4 x USB 2.0/1.1 port(s) (4 at mid-board) |
|
| HDMI Port | 1 x HDMI | |
| DVI-D Port | 1 x DVI-D | |
| D-SUB Port | 1 x D-Sub | |
| LAN Port | * Realtek® RTL8111H, 1 x Gigabit LAN * ASUS LAN Guard |
|
| Audio Port | * Realtek® ALC887 8-Channel High Definition Audio CODEC - Supports : Jack-detection, Front Panel Jack-retasking - LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path. - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals - Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity * Choose the chassis with HD audio module in front panel to support 8-channel audio output. |
|
| Other Information | ||
| Special Features | ASUS 5X Protection III : - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges! - ASUS Overvoltage Protection: World-class circuit-protecting power design - ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability! - ASUS DIGI+ VRM: Premium components provide better power efficiency ASUS OptiMem： - Optimem (Improved DDR4 stability) ASUS EPU : - EPU ASUS Exclusive Features : - AI Suite 3 - Ai Charger - PC Cleaner ASUS Quiet Thermal Solution : - Stylish Fanless Design Heat-sink solution - ASUS Fan Xpert 2+ ASUS EZ DIY : - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode ASUS Q-Design : - ASUS Q-DIMM M.2 Onboard(The latest transfer technologies with up to 32Gb/s data transfer speeds) |
|
| Operating System | ||
| Supported OS | Windows® 10 64-bit |
|
| Warranty | ||
| Warranty | 03 Years Warranty |
|
Asus Prime B365M-A motherboards give you the strong foundation you expect in your first form, in addition to the versatility of developing with your aspirations. We've put together all the cool stuff with basic planning and design in the latest 8th/9th Generation Intel Celeron/Pentium®/Core i3/i5/i7 Processors support, so you can benefit from industry-driven advances, including tuning of mechanical structures. Extensive cooling control, and lively locally available sound.
For more Motherboard information Please Check Gigabyte Motherboard, MSI Motherboard, Asus Motherboard, Esonic Motherboard, and Asrock Motherboard. And also If you Want to know more different type of IT Product information please Click here.
Asus Prime B365M-A Motherboard comes with 8th/9th Generation Intel Celeron/Pentium®/Core i3/i5/i7 Processors, 1151 Socket, Build in Intel B365 Chipset with 128 Mb Flash ROM, UEFI AMI BIOS, 24.4 cm x 21.8 cm ATX Form Factor. Asus Prime B365M-A Motherboard Maximum 64 GB DDR4 Dual Channel Memory, 4 x DDR4 DIMM sockets, Supported Bus Speed 2666/ 2400/ 2133 MHz. Asus Prime B365M-A Asus Motherboard comes with standard Graphics such as Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 30 Hz, DVI with max. resolution 1920 x 1200 @ 60 Hz, D-sub with max. resolution 1920 x 1200 @ 60 Hz, Maximum shared memory of 1024 MB. Asus Prime B365M-A Motherboard Expansion PCI Slots is 1 x PCIe 3.0/4.0 x 16 slots, 6 x SATA 6 GB/s, 1 x M.2_2 socket 3, Supported Raid 0, 1, 5, 10 also various Internal Connectors such as 1 x 24-pin ATX main power connector, 1 x 4 pin CPU fan header, 1 x M.2_FAN connector, etc. The Asus Prime B365M-A Motherboard has Realtek RTL8111H, 1 x Gigabit LAN, ASUS LAN Guard, 7 USB 3.2 Gen 1, 4 USB 2.0 ports, Realtek ALC887 8-Channel High Definition Audio CODEC. Asus Prime B365M-A Motherboard has some special features like ASUS Exclusive Software.
Asus Prime B365M-A Motherboard Support for Windows 10 64-bit. You can enjoy 03 Years Warranty. Purchase Motherboard from Original Store Ltd and get online conveyance at any side of Bangladesh.
