DeepCool PF550 80 PLUS Standard Power Supply

Price :           To be announced
Status :           Out of Stock
Brand :           Deepcool

Short Details:

  • • Model: DeepCool PF550
  • • Capacity: 550W
  • • Type: ATX12V V2.4
  • • Fan Size: 120mm

See More Details

Price: To be announced
EMI Offer(EMI for 6 to 24 Months)
Quantity
General Information
Model PF550
Brand DeepCool
Capacity 550W
Color Black
RGB Fan No
Form Factor ATX
Type ATX12V V2.4
PFC Active
Power Good Signal 100-500ms
Hold Up Time ≥16ms(75% Load)
MTBF 100,000 Hours
Fan Size 120mm
Protections OPP/OVP/SCP/UVP
80PLUS Certifications 230V EU White
Fan Bearing Hypro Bearing
Connector Information
Main Power Connector 24 (20+4)Pin x1
EPS 12V Connector 8 (4+4)Pin x1
PCI-E (6+2)Pin x2
SATA SATA x3 + 4Pin Peripheral x1
Physical Information
Dimensions 150×140×86mm (W x L x H)
Warranty
Warranty 05 Years

Description:


DeepCool PF550 80 PLUS Standard Power Supply


DeepCool PF550 80 PLUS Standard Power Supply. The DeepCool PF Series Power Supply Unit offers safe and stable power performance with reliable 80 PLUS Standard efficiency and affordable pricing.


DeepCool PF550 80 PLUS Standard Power Supply. The Model DeepCool PF550. The Power Supply Capacity is 550W. The Color is Black. RGB Fan No. Form Factor ATX. Type ATX 12V V2.4. PFC Active. Power Good Signal 100-550ms. Hold Up Time ≥16ms (80% load). MTBF 100,000 Hours. Cooling Fan System 120mm. Protections OPP/OVP/SCP/UVP. 80PLUS Certifications 230V EU White. Fan Bearing Hypro Bearing. Main Power Connector 24 (20+4)Pin x1. EPS 12V Connector 8 (4+4)Pin x1. PCI-e (6+2)Pin x2. SATA x3 + 4Pin Peripheral x1. Dimensions 150×140×86mm (W x L x H). The DeepCool PF550 80 PLUS Standard Power Supply has comes 05 Years warranty.
